Whirlpool YWML55011HS Over the Range Microwave,
30 inch Exterior Width, 1.1 cu. ft. Capacity, 400 CFM, 900 W Watts, Halogen , Stainless Steel colour
| Specification | Value |
|---|---|
| Capacity | 1.1 Cu Ft |
| Capacity (Litres) | 31.13 L |
| Common Width Class | 30 inches |
| Width | 29-7/8 inches |
| Width (Centimetres) | 75.88 cm |
| Height | 10-5/16 inches |
| Height (Centimetres) | 26.19 cm |
| Depth | 18 inches |
| Depth (Centimetres) | 45.72 cm |
| Depth with Door Open 90° | 42-1/8 inches |
| Depth with Door Open 90° (Centimetres) | 107.0 cm |
| Interior Width | 19 inches |
| Interior Width (Centimetres) | 48.26 cm |
| Interior Height | 7 inches |
| Interior Height (Centimetres) | 17.78 cm |
| Interior Depth | 15 inches |
| Interior Depth (Centimetres) | 38.10 cm |
| Net Weight | 57.2 lbs |
| Net Weight (Kilograms) | 25.95 kg |
| Gross Weight | 64 lbs |
| Gross Weight (Kilograms) | 29.03 kg |
| Microwave Type | Over-the-Range Microwave Hood Combination |
| Configuration | Low Profile Microwave Hood Combination |
| Cooking Power | 900 Watts |
| Number of Power Levels | 10 |
| Turntable | Recessed, Stoppable |
| Turntable Diameter | 12 inches |
| Turntable Diameter (Centimetres) | 30.48 cm |
| Microwave Interior Finish | Powder Coat |
| Microwave Interior Light | Halogen |
| Work Surface Light | Halogen |
| Convection | No |
| Grill | No |
| Sensor Cooking | No |
| Ventilation Type | Updraft |
| Venting Options | Exterior or Recirculating |
| CFM Motor Class | 400 CFM |
| Number of Vent Speeds | 3 |
| Blower Type | Centrifugal |
| Duct Direction | Vertical or Horizontal |
| Duct Type | Rectangular |
| Duct Outlet Size | 3.25 in x 10 in |
| Filters | Charcoal Odor Removing Filter |
| Night Light | Yes |
| Vent Fan Location | Side |
| Control Type | Electronic Touch |
| Control Location | Right Front |
| Display Type | LED |
| Display Color | White |
| Number of Keypads | 24 |
| Number of Convenience Control Pads | 6 |
| Clock | Yes |
| One Touch Cooking | No |
| Door Opening Direction | Left |
| Door Release | Touch to Open (Tap-To-Open Door) |
| Door Hinge | Left |
| Door Hinge Opening Angle | 90° Hinge Door |
| Cabinet / Exterior Color | Stainless Steel |
| Finished Sides | Yes |
| Low Profile Design | Yes |
| Add 30 Seconds Option | Yes |
| Turntable On/Off Option | Yes |
| Microwave Presets | Yes |
| Convenience Cooking Controls | Yes |
| Control Lock | Yes |
| End of Cycle Signal | Yes |
| Sound On/Off | Yes |
| Popcorn Preset | Yes |
| Pizza Preset | Yes |
| Beverage Preset | Yes |
| Soup Preset | Yes |
| Dinner Plate Preset | Yes |
| Fresh Vegetable Preset | Yes |
| Frozen Vegetable Preset | Yes |
| Frozen Entrée Preset | Yes |
| Auto Cook | Yes |
| Auto Defrost / Defrost | Yes |
| Reheat Preset | Yes |
| Timer | Yes |
| Pause / Stop | Yes |
| Off / Cancel | Yes |
| Electrical Requirements | 120 V / 60 Hz / 15 A |
| Amps | 15 A |
| Voltage | 120 V |
| Frequency | 60 Hz |
| Connectivity | No |
| Smart Compatibility | Not Wi-Fi / Smart enabled |
| Certifications – UL | Yes |
| Certifications – cUL | No |
| Prop 65 | Yes (California warning) |
| Country of Origin | China |
| Optional Accessories | W11185746 |
• Tap‑to‑Open Door – gently tap the door with your wrist or elbow to open, so you can access the microwave without putting hot or heavy dishes down.
• Concealed Touch Controls – smooth electronic touch panel hidden behind the door for a clean, modern look and easier wipe‑down.
• 3‑Speed, 400 CFM Motor Class High Performance Venting – powerful exhaust fan quickly removes smoke, steam and cooking odours to help keep kitchen air fresh.
• Turntable On/Off Feature – choose to rotate dishes for even heating or turn the turntable off to fit large or rectangular cookware.
• Add 30 Seconds Button – instantly start or extend cooking in 30‑second increments with a single touch, without re‑entering settings.
• Multiple Speed Exhaust Fan – three selectable fan speeds let you match ventilation power to what you’re cooking, from simmering to frying.
• Adjustable Cooktop Lighting – built‑in halogen work‑surface light with adjustable brightness to illuminate the range or cooktop below.
• Low Profile MHC Microwaves design – shallow height allows installation in spaces normally used for under‑cabinet hoods while still offering full‑width coverage.
• 1.1 cu. ft. Capacity – purposeful interior space fits tall glasses, wide plates and mixing bowls while maintaining a slim exterior profile.
• 900–1000 W Cooking Power (model‑dependent) – high microwave power for fast reheating, cooking and defrosting of everyday meals.
• 10 Power Levels – fine‑tune the microwave intensity to help prevent undercooking or overcooking different types of food.
• Microwave Presets – pre‑programmed settings automatically set time and power for common tasks like reheating, defrosting and cooking vegetables.
• Popcorn Preset – dedicated one‑touch button automatically adjusts time and power to help pop popcorn bags thoroughly while reducing burning.
• Auto Defrost Options – defrost by time or preset to thaw meats, poultry and other frozen foods more evenly than at full power.
• Reheat and Dinner Plate settings – specialized presets warm leftovers and full plates of food without drying them out.
• Beverage and Soup presets – one‑touch options heat drinks and soups to serving temperature without boiling over.
• Fresh and Frozen Vegetable presets – tailored programs help cook vegetables from fresh or frozen for better texture and flavour.
• Pizza and Frozen Entrée presets – optimized settings for reheating pizza slices and cooking frozen meals conveniently.
• Control Lock (Child Lock) – disables the control panel to help prevent unintended use or changes to settings, especially by children.
• Clock and Kitchen Timer – built‑in digital clock and timer support everyday cooking and time management.
• End‑of‑Cycle Signal – audible alert lets you know when cooking is finished so food doesn’t sit too long in the microwave.
• Sound On/Off option – allows you to mute keypad and end‑of‑cycle tones for quieter operation in open‑concept spaces or at night.
• Night Light feature – gentle, energy‑efficient light setting provides soft illumination of the cooktop and kitchen at night.
• Halogen Interior Light – bright interior lighting makes it easy to monitor food without opening the door.
• Recessed, Stoppable Turntable – 12″ recessed glass turntable maximizes usable interior height and can be stopped when needed for large dishes.
• Dishwasher‑Safe Turntable Plate – removable glass tray can be placed directly in the dishwasher for easy cleanup of spills and splatters.
• Charcoal Odor Removing Filter – helps capture and reduce cooking odours when using recirculating (non‑vented) installation.
• Exterior or Recirculating Venting – flexible installation allows venting to the outside or filtering and recirculating air back into the kitchen.
• Updraft Ventilation with Rectangular Ducting – designed to vent air upward through standard rectangular ductwork for compatibility with many existing setups.
• Fan Speed Indicator – visual indicator shows which ventilation speed is selected for quick confirmation at a glance.
• Electronic LED Display – clear, easy‑to‑read white LED display shows time, cooking progress and function selections.
• Right‑Front Control Location – conveniently placed controls on the right side of the front panel for intuitive access.
• Touch‑to‑Open Door Release – electronic door release mechanism provides smooth, consistent opening without a mechanical handle.
• Left‑Swing 90° Hinge Door – door opens to a full 90 degrees on the left side, allowing installation next to a wall or cabinet.
• Finished Cabinet Sides – finished side panels provide a clean, built‑in appearance even when the microwave is exposed on one or both sides.
• Powder‑Coated Interior Cavity – durable, easy‑to‑clean interior surface resists staining and simplifies wiping up spills.
• Compact 30″ Width – designed to fit standard 30‑inch range and cabinet openings for straightforward replacement of existing over‑the‑range units.
• Standard 120 V, 15 A Electrical Connection – plugs into a typical household outlet, simplifying installation in most kitchens.
• Non‑Convection Design – straightforward microwave‑only operation for users who prefer simple, familiar cooking functions.
• No Wi‑Fi or Smart Connectivity – avoids network setup and app dependence for customers who want an appliance that works entirely from the front panel.
Manufacturer’s Warranty: 1 year
Canadian model: YWML55011HS
Similar to USA model: WML55011HS
Canadian UPC: 883049469041
Similar to USA UPC: 883049468921
EAN: 0883049469041
